Product Details:
The product is available as thin brick and can be manufactured to meet PCI physical property requirements* and withstand the 1,000 psi pressure. This product is typically cut to 3/4" thickness, but can be cut to 7/8" or thicker, which would include a ribbed back. It is available in the sizes listed below up to 12” lengths. Please contact the Hanley Plant directly at (814) 856-2171 for more information.
*Listed in the 3rd edition of the Architectural Precast Handbook
Product Information:
Brand:
Glen-Gery
Type:
Facebrick
Color:
Grey
Style:
Klaycoat
Plant:
Hanley
Series/Collection:
Designer Klaycoat® Series
Texture/Finish:
Smooth
| General Availability | T | H | L | |
|---|---|---|---|---|
| Modular | 3-5/8 | 2-1/4 | 7-5/8 | in. |
| Special Order | T | H | L | |
|---|---|---|---|---|
| Standard | 3-5/8 | 2-1/4 | 8 | in. |
| Engineer Modular | 3-5/8 | 2-3/4 | 7-5/8 | in. |
| Engineer Standard | 3-5/8 | 2-3/4 | 8 | in. |
| Norman | 3-5/8 | 2-1/4 | 11-5/8 | in. |
| Econo | 3-5/8 | 3-5/8 | 7-5/8 | in. |
| Utility | 3-5/8 | 3-5/8 | 11-5/8 | in. |
Test Report:
Cleaning Document:
Product Profile:
Safety Data Sheet:
